Answer to Question #202594 in Mechanical Engineering for Adarsh maurya

Question #202594

From the following data, draw the profile of a cam in which the follower moves

with simple harmonic motion during ascent while it moves with uniformly

accelerated motion during descent : Least radius of cam = 50 mm ; Angle of

ascent = 48° ; Angle of dwell between ascent and descent = 42° ; Angle of descent

= 60° ; Lift of follower = 40 mm ; Diameter of roller = 30 mm ; Distance between

the line of action of follower and the axis of cam = 20 mm. If the cam rotates at

360 r.p.m. anticlockwise, find the maximum velocity and acceleration of the

follower during descent


1
Expert's answer
2021-06-08T15:12:02-0400

ω=2πN60=2π×24060=25.14rad/s.ω = \frac{2πN}{60}=\frac{2π×240}{60} = 25.14 rad/s.

vO=πωS2θO=π×25.14×0.042×1.571=1m/s.v_O=\frac{πωS}{2θ_O} =\frac{π×25.14×0.04}{2×1.571}= 1 m/s.

vR=πωS2θR=π×25.14×0.042×1.047=1.51m/s.v_R=\frac{πωS}{2θ_R }=\frac{π×25.14×0.04}{2×1.047}= 1.51m/s.

aO=π2ω22(θo)2=π2(25.14)2×0.042(1.571)2=50.6m/s.a_O= \frac{π^2ω^2}{2(θ_o)^2} = \frac{π^2(25.14)^2×0.042}{(1.571)^2} = 50.6 m/s.

aR=π2ω22(θR)2=π2(25.14)2×0.042(1.047)2=113.8m/s.a_R=\frac{ π^2ω^2}{2(θR)^2 }=\frac{ π^2(25.14)^2×0.042}{(1.047)^2}= 113.8 m/s.
