Answer to Question #232606 in Electrical Engineering for AMAL KHAN

Question

Traffic intensity is one of the important ratio which gives an insight into the queuing delays.

Discuss traffic intensity and its impact on the queue’s behaviour of a router for the following

cases: (i) Traffic Intensity >1 (ii) Traffic Intensity < 1 (iii) Traffic Intensity =1. (You have to

explain your answer with the help of mathematical equations and graph).

Answer 1

A traffic intensity of more than 1 or (Traffic Intensity >1 ): This implies that that the speed at which bits come is above the rate bits can be transmitted and queuing delay will increase without bound as shown below:
